Client API reference

Board id

:boardId is the board slug (string), e.g. b. Unknown board → 404 { "error": "Board not found" }.

JSON conventions

• Content-Type: application/json for JSON request bodies.
• Timestamps: UTC ISO 8601 strings in timestamp fields.
• Errors: failures return JSON { "error": "<message>" } with an appropriate 4xx/5xx status.

Cookies

If absent, the server sets it on the response.

CSRF

Some POSTs require a CSRF token sent as a request header.

Flow

1. GET /csrf-token → { "token": "<hex>" }
2. Send the token on the next mutating request as header x-csrf-token: <token> (alias: csrf-token).
3. Fetch a fresh token before the next protected POST.

Missing/invalid → 403 with { "error": "Missing CSRF token" } / { "error": "Invalid CSRF token" }.

Read API — prefix /api

All GET. Write endpoints under /api are subject to server-side rate limiting; exceeding limits returns 429 with a JSON error.

GET /api/:boardId — board index

Query

Response: JSON array of thread objects (newest activity first):

{
  "originalPost": { "id", "thread_id", "subject", "trip", "name", "email", "timestamp", "message", "file", ... },
  "replies": [ { "...post fields...", "isOpReply": true } ]
}

• originalPost / replies: public post fields only.
• isOpReply: present when a reply is from the same client identity as OP.
• mentions: optional aggregate of backlinks (threadOpId|citingPostId, …).
• board_post_no: 0-based index of the post on the board.
• embed_kind / embed_youtube_id: populated when embed_url is set.

GET /api/:boardId/catalog — catalog of recent OPs

Returns an array of OP rows (not split into originalPost / replies) with the same public columns plus board_post_no, ISO timestamps, and embed augmentation. Server-side capped to a small number of threads.

GET /api/:boardId/p:id — single post by global id

Path is /api/{board}/p{numericId} in one piece (example: /api/b/p100).

Returns an array of one post, or empty/404 if not found.

GET /api/:boardId/:thread — full thread as flat post list

:thread = OP / thread root numeric id.

Returns a JSON array of posts ascending by id: [op, ...replies]. Same per-post shape as catalog rows. Not the { originalPost, replies } wrapper used on the board index.

GET /api/update/:boardId/:thread_id/:from — poll new replies

Returns posts in the thread with id greater than from. Params must be valid integers.

If you suspect missed updates, refetch the full thread via GET /api/:boardId/:thread.

Write API — JSON — prefix /api

POST /api/thread/:boardId — new thread

Body

Success: JSON array of inserted ids, e.g. [123] (new OP id equals thread id).

Common errors: 400 validation, 403 not allowed, 429 throttled.

POST /api/:boardId/:threadId — reply

Body: message, optional mod_sign.

Success: [<newPostId>].

Common errors: 400 invalid board/thread, 403 not allowed, 429 throttled.

Write API — multipart / form (attachments)

Paths under site root (no /api prefix). Require a CSRF token (see above) and are rate-limited.

POST /:boardId/thread — new thread with file and/or embed

• multipart/form-data or urlencoded form.
• Fields: message (required unless a file or embed_url is present), embed_url optional, mod_sign optional. Sending a file together with embed_url → 400.

Files are validated for type and size; oversize, disallowed type, or excessive upload volume returns 4xx/429. A duplicate file on the same board returns 409 { "error", "duplicatePostId" }.

Success: 302 redirect to /{boardId} (HTML flow). Errors may be returned as JSON.

POST /:boardId/thread/:threadId — reply with attachment

Same rules as new thread.

Success: { "success": true }.

Media URLs

Uploaded files are served under /media/. The file and thumb fields on posts are filenames relative to that path.

WebSocket (optional realtime)

Connect a WebSocket client to the same host.

GET /ws/thread — new replies in a thread

After open, send UTF-8 JSON:

Subscribe

{ "op": "sub", "boardId": "<slug>", "threadId": <number> }

Unsubscribe

{ "op": "unsub", "boardId": "<slug>", "threadId": <number> }

Server → client

Payload does not include post bodies.

GET /ws/presence — site-wide “online” estimate

Connect only; the server periodically broadcasts:

{ "t": "online", "uniqueIps": <number> }

Reverse proxies must forward Upgrade and Connection headers for WebSockets.

Suggested client flows

1. Board list: GET /api/{board}?limit=&offset=.
2. Open thread: GET /api/{board}/{threadId} (flat list) or compose from index card.
3. Live thread: open /ws/thread, sub, on {t:"reply"} call GET /api/update/{board}/{threadId}/{lastKnownPostId} or refetch the full thread.
4. Post text (no file): POST /api/thread/{board} / POST /api/{board}/{threadId} with JSON message.
5. Post with file: GET /csrf-token → multipart POST /{board}/thread or .../thread/{id} with header x-csrf-token and cookies.
